D Series
D Series
- Product details
- Product brief
| 型号MODEL | D-2400 | D-3200 | D-4000 |
| STEREO POWER(8Ω) | 4x600W | 4x800W | 4x1000W |
| STEREO POWER(4Ω) | 4x900W | 4x1200W | 4x1500W |
| 8Ω桥接功率 | 2x1800W | 2x2400W | 2x3000W |
| SIGNAL TO NOISE | ≥105dB | ||
| SLEW RATE | 88V/uS | 90V/uS | 90V/uS |
DAMPING FACTOR | ≥480 | ≥450 | ≥440 |
| FREQUENCY RESPONSE | 20Hz-20KHz,±0.5dB | ||
| THD+N | ≤0.5%，1KHz，1/3 Rate Power ,8Ω | ||
| IMD | ≤0.1%，1KHz，1/3 Rate Power ,8Ω | ||
| CROSS TALK | ≥78dB | ≥80dB | ≥85dB |
| INPUT SENSITIVITY | 0dBv(1V),BALANCE | ||
| INPUT IMPEDANCE | 20KΩ，BALANCE/10KΩ，UNBALANCE | ||
| INPUT CONNECTOR | Three-core Caron(XLR) INPUT | ||
| OUTPUT CONNECTOR | 1/4# SPEAKON，BINDING POST | ||
| INDICATOR | SIGNAL(-40dB)，CLIP(PEAK)，MUTE | ||
| POWER | 1900W | 4900W | 6200W |
| COOLING MODE | FRONT TO REAR STEPLESS AIR COOLING FAN | ||
| INSTALL SIZE | 483Wx385Dx89H | ||
Model
D-2400/3200/4000
